Specifications
● Adopt PLC touch screen control including the functions of indications of auto counting, speed, production, skip feeding and alarms;
● All transmission rollers are made of top quality steel processed through dynamic/static balance tests, chrome plating and polishing;
● China famous brand of transmission gears are adopted which are hardened and ground＞60o Rockwell hardness;
● Main bearings from HRB
● Main electric components are purchased from the suppliers such as SCHNEIDER France and OMRON Japan;
● Spline free joint ring are employed to reduce center abrasion and remain precise registration for a long time;
● Auto zeroing and auto reset;
● Every unit of overall machine can be released automatically or separately, electric shifting and pneumatic locking with acoustic alarm in traveling to secure operators safety. The auto brake is able to stop machine running;
● Emergent protection: emergency switch is installed inside every unit to stop unit running inside machine for more security;
● The clearances of pull rollers, impression cylinder, rubber cylinder and anilox cylinder are all auto pneumatically locked.
● Specially made 7.5kW high pressure centrifugal fan, suction auxiliary feeding paper, smooth transmission, to ensure the smooth surface of the thin surface and lower quality of the smooth transmission of the board, the effect is obvious.
Lead feeder
● Automatic suction lead edge feeder equipped with a 7.5kw suction fan to feeding cardboard, the blowing rate is adjustable by the transducer according to the degree of crook of cardboard in order to transmit cardboard smoothly.
● Use 7inch touch screen
● The main control panel is composed of control buttons and touch screen, which is very convenient and reliable.
● The machine is launched by pressing the start button with two hands, which ensure the operator's safety.
● The side plate is electrical adjusted automatically while the backstop is adjusted manually.
● Sheet cleaner is equipped to remove the contaminants on the cardboard which will improves the printing quality.
● The upper transmission roll is made of seamless steel tube, the surface is covered wear proof rubber, which is also good at avoiding crushing the cardboard.
● The lower transmission roll is made of seamless steel tube, with the treatment of grinding, embossing, and chrome plated.
● The transmission between the upper and lower transmission roll is driven by double slider coupling, which is good at reducing wear down and transmitting smoothly.
● The transmission shaft equipped with electromagnetic friction clutch, for avoiding damaging the motor in case of misoperation or overload.
● Automatic counter for recording the cardboard supply quantity to show the output.
● Can Save orders, the number can reach about 100+.It is easy to operate in next time.
Die cutting unit(combined with lead edge)
Die cutting upper roller
(1) surface grinding, plating hard burger, move smoothly(Taiwan maxdura 9mm thick rubber resistance).
(2) has speed limit compensation device.
(3) rubber roller to move transversely 40 mm, prolong the service life of the rubber.
(4) automatic repair device, improve pads utilization rate, can repair the three to four times.
Die cutting bottom roll
(1) surface grinding, plating hard burger.
(2) equipped with lift roller, no cardboard, down roller to be automatic drop, reduce wear rubber roller.
Pahse adjustment
(1) the planet type gear structure.
(2) the tacit understanding phase PLC and LCD control and electric digital 360 ° adjustment. (operation, stop all can adjust)
